Silent Angel - Munich M1V2-4GB - High Performance Music Streamer

Silent Angel - M1V2-4GB - High Performance Music Streamer
The Silent Angel Munich M1 V2 4GB is a compact HiFi-grade network streamer built for listeners who want dedicated digital playback without relying on a computer as the main audio source. Its VitOS operating system is designed for low-latency, stable music playback, with support for Qobuz, Spotify Connect, AirPlay, DLNA, Roon Ready operation, and network or USB-based music libraries.
The M1 V2 uses a 4-core ARM Cortex-A72 processor and 4GB of system memory to support streaming buffers, app performance, and multi-application playback. Digital output options include AES/EBU, I2S, coaxial, and USB Audio, allowing the M1 to work as a dedicated transport for external DACs. USB Audio supports PCM up to 768kHz and DSD256, while the coaxial, AES/EBU, and I2S outputs support PCM up to 384kHz and DSD128.
For direct listening, the Munich M1 V2 includes a built-in DAC, RCA analog outputs, volume control, and a front-panel 6.35mm headphone jack. Its fanless aluminum enclosure, EMI absorption, gold-plated output ports, and efficient heatsink design help reduce unwanted noise and improve long-term reliability. The result is a flexible streamer for powered speakers, headphone setups, external DAC systems, and compact two-channel HiFi installations.
FEATURES:
- Compact HiFi-grade network streamer for digital music systems
- Runs Silent Angel VitOS audio-optimized operating system
- 4GB system memory supports streaming buffers and app performance
- Supports Qobuz, Spotify Connect, AirPlay, DLNA, and Roon Ready
- USB Audio output supports PCM up to 768kHz and DSD256
- AES/EBU, I2S, and coaxial outputs support external DACs
- Built-in DAC supports RCA analog output
- Front 6.35mm headphone jack supports direct headphone listening
- Gold-plated audio ports improve long-term signal connection quality
- Fanless aluminum enclosure helps reduce vibration and operating noise
SPECIFICATIONS:
| Product Type | HiFi Music Streamer |
| Available Color | Black |
| Operating System | Silent Angel VitOS |
| CPU | 4-Core 1.5GHz ARM Cortex-A72 |
| System Memory | 4GB |
| Power Consumption | 10W Maximum |
| Streaming Support | Qobuz, Spotify Connect, AirPlay, DLNA, Roon Ready, Internet Radio |
| Music File Support | AAC, M4A, MP3, OGG, FLAC, WAV, ALAC, DSD, WAV64, AIFF, CUE, WMA, APE |
| Gapless Playback | Supported |
| MQA Handling | MQA Supported Through USB Audio Output to Compatible DACs |
| Digital Outputs | AES/EBU x 1, I2S x 1, Coaxial x 1 |
| Digital Output Resolution | PCM up to 384kHz, DSD up to DSD128 |
| USB Audio Output | USB Audio x 1 |
| USB Audio Resolution | PCM up to 768kHz, DSD up to DSD256 |
| Analog Output | RCA L/R Output |
| Headphone Output | 6.35mm Headphone Jack x 1 |
| Headphone Output - 33 ohms | 1mW THD+N: 0.0035%; Maximum 375mW THD+N: 0.002% |
| Headphone Output - 590 ohms | Maximum 27.5mW THD+N: 0.0015% |
| External Storage USB | USB 3.0 x 2, USB 2.0 x 1 |
| Ethernet | 1GbE RJ45 x 1 |
| Reserved Ports | M-IO x 1, M-LINK x 1 |
| LED Indicators | Mute LED x 1, Power LED x 1, Digital Output LED x 2 |
| Operating Temperature | 32°F to 86°F (0°C to 30°C) |
| Storage Temperature | -4°F to 158°F (-20°C to 70°C) |
| Operating Humidity | 10% to 90% RH, Non-Condensing |
| Storage Humidity | 5% to 95% RH, Non-Condensing |
| Dimensions (W x H x D) | 6.1" x 1.9" x 4.3" (155.19mm x 50.55mm x 110.24mm) |
| Weight | 2.2 lbs (1.0kg) |
| Warranty | One Year (3 years with registration) |
