The enjoyment of music is at the core of our designs. RS1 is not about thunderous, overblown bass, but about deep, controlled, and most importantly a musical sound. To achieve this, the enclosure and custom drivers have been optimised and tuned to deliver natural extended bass, that is fast and rhythmic.

The reason for the development of RS1, was due to the demand from customers requesting a companion sub for our award winning MR1 Bluetooth speakers. We also saw that there was a need for a subwoofer with style. Where many subs look unattractive in a domestic environment, the tailored grille and hand-crafted wood panels of RS1 means it fits seamlessly with other furnishings, making it a product that customers will be proud to display in their homes.

RS1 delivers deep bass that smaller speakers are unable to, giving a more satisfying and realistic audio experience. It’s a perfect addition to our MR1 and R3S models or indeed any other system where a subwoofer with style and good sound is required, providing the joy of bass in every note and song.

FEATURES:

Cabinet Tuned passive radiator enclosure
Auto on Automatically turns on and sleeps after 15 minutes when no signal is detected
Compatible with our MR1, R3S and R410 models or any other active speaker or amplifier with subwoofer or pre-out phono connectors
Slate Grey cabinet cloth with Rich Walnut or Satin Charcoal lacquer top and bottom panels
Adjustable crossover 50–180Hz, input/volume level control and 180 degree phase switch
Box contains RS1 subwoofer, mains lead, 3m RCA connector lead and quick start guide

SPECIFICATIONS:

Output Power:	100W RMS This Rating not tested under the FTC Standard
Output Power:	100W RMS This Rating not tested under the FTC Standard
Driver:	6.9" treated fibre long-throw active driver and 6.9" passive radiator
AC power input:	100-240V, 50-60Hz
Amplifier:	RMS Class D with soft clipping filter
Frequency Response (±3dB):	25Hz – 200Hz
Input:	Sub-input via Mono RCA input (up to 2.3Vrms)
Power consumption:	0.5W standby, 2.0W idle
Dimensions:	H 11.8" × W 9.8" × D 10.4" (inc. feet and controls)
Weight:	14.7 lbs (6.7kg)

DOWNLOADS:

Ruark - RS1 - User Guide (PDF)
