Advance Paris X-FTB01 is a compact Bluetooth receiver designed to add wireless audio playback to compatible Advance Paris components. It works with products from the Classic, MyConnect, PlayStream, and Smart ranges that include a dedicated BT port. For listeners who want simple wireless access from a phone, tablet, computer, or portable player, the X-FTB01 provides an easy way to bring Bluetooth into an existing hi-fi system.
Setup is straightforward, with the X-FTB01 connecting directly to the Bluetooth input of a compatible amplifier or receiver. Once connected, the blue LED flashes during pairing and becomes fixed after the connection is made. The quick start manual notes that the device appears under the name X-FTB01 in the Bluetooth menu and does not require a PIN code for pairing, keeping daily use simple.
The X-FTB01 supports aptX Bluetooth and is built for convenient music playback from dematerialized sources without adding a full-size component to the system. Its small 2.17" W x 0.51" H x 1.10" D footprint allows it to stay tucked neatly behind compatible Advance Paris equipment. With Bluetooth 4.2 aptX support, 20Hz-20kHz frequency response, and direct BT-port compatibility, the Advance Paris X-FTB01 is a clean upgrade for adding wireless playback to supported Advance Paris systems.
FEATURES:
- Compact high-definition Bluetooth receiver for Advance Paris systems
- Bluetooth 5.0 support for modern wireless playback
- Supports AAC, aptX, aptX LL, aptX HD, and SBC codecs
- aptX HD supports 24-bit wireless audio quality
- Dual Core 32-bit processor with 120MHz single core
- Direct digital output stage preserves the original audio signal
- Designed for compatible Advance Paris products with BT input
- No PIN code required for standard Bluetooth pairing
- Blue LED indicates pairing and connection status
- Compact plug-in design keeps system setup simple
SPECIFICATIONS:
| Product Type | Bluetooth Receiver |
| Model | X-FTB02 |
| Bluetooth Codecs | AAC, aptX, aptX LL, aptX HD, SBC |
| Audio Interfaces | 24-bit |
| Processing | Tri-Core Processing; Dual Core 32-bit with 120MHz Single Core |
| DAC Use | Direct Digital Signal Path; Conversion Handled by Downstream DAC |
| Frequency Response | 20Hz-20kHz, +/-0.5dB |
| Total Harmonic Distortion | 0.003% at 1kHz |
| Dynamic Range | >120dB |
| Transmission Distance | 32.81' (10m), Class II |
| Bluetooth Frequency Band | 2.402GHz-2.480GHz ISM Band |
| RF Output Power | 4dBm, Class II |
| Pairing Name | X-FTB02 |
| Dimensions (W x H x D) | 2.1" x 0.5" x 1.1" (55mm x 13mm x 28mm) |
| Net Weight | 0.02 lbs (10g) |
| Gross Weight | 0.04 lbs (20g) |
